| 外殼材質 | Housing Material | 粉末冶金 |
| 輸出軸承形式 | Bearing at output | 含油軸承 |
| 徑向負載 | Radial load (10mm from flange) | ≤35(N) |
| 軸向負載 | Shaft axial load | ≤15(N) |
| 靜態主軸最大承受壓入力 | Shaft press fit force max Static | ≤80(N) |
| 徑向間隙 | Radial play of shaft | ≤0.08(mm) |
| 軸向間隙 | Thrust play of shaft | ≤0.4(mm) |
| 背隙（無負載時） | Backlash at no-load | ≤1.5° |
*負載與轉速有關，具體數據需參考實際情況。
*Load relates to speed, actual value depends on different situation.
| 減速比 | 額定允許負載（Nm） | 瞬間允許負載（Nm） | 效率（%） | 長度 | 重量 | 減速比級數 |
|---|---|---|---|---|---|---|
| 1/4 | 0.1 | 0.3 | 81% | 13.9 | 29 | 1 |
| 1/4.75 | 0.1 | 0.3 | 81% | 13.9 | 29 | 1 |
| 1/16 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/19 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/22 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/26 | 0.4 | 1.2 | 72% | 32.4 | 52 | 2 |
| 1/64 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/76 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/88 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/104 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/121 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
| 1/144 | 0.8 | 2.5 | 65% | 43.9 | 73 | 3 |
