更多PG56A-PM-HT系列產品請致電0519-88385510或郵件info@ht-motor.com
| 外殼材質 | Housing Material | 粉末冶金 |
| 輸出軸承形式 | Bearing at output | 滾珠軸承 |
| 徑向負載 | Radial load (10mm from flange) | ≤450(N) |
| 軸向負載 | Shaft axial load | ≤200(N) |
| 靜態主軸最大承受壓入力 | Shaft press fit force max Static | ≤1000(N) |
| 徑向間隙 | Radial play of shaft | ≤0.03(mm) |
| 軸向間隙 | Thrust play of shaft | ≤0.1(mm) |
| 背隙（無負載時） | Backlash at no-load | ≤1.5° |
*負載與轉速有關，具體數據需參考實際情況。
*Load relates to speed, actual value depends on different situation.
